Weatherproof 15 Meters Long Distance UHF Card Reader Antenna Wiegand26/RS232 interface For Car Parking System
Main Features
1. Self-intellectual property;
2. Support ISO18000-6C(EPC C1G2) protocol tag;
3.Operating frequency: 902~928MHz frequency band(frequency customization optional);
4. FHSS or Fix Frequency transmission;
5. RF output power up to 30dbm(adjustable);
Technical Parameters
Working Frequency: 902-928MHz
Reading Distance: stable is 12M.maximal is 30M
Recognition Speed: >120km/h
Support protocol: ISO-18000-6B or ISO-18000-6C(EPC G2)
Antenna Gain: 12dbi
Polarization: horizontal polarization
Voltage: 12VDC ± 10%
Current: <400mA
Power consumption: <5W
Communications interface: Wiegand26bit 34bit 42bit RS232 RS485 10/100M Ethernet
Operating Temperature: -40 °C ~ +85 °C (industrial grade)
Storage temperature: -60 °C ~ +85 °C
Operating humidity: 10% ~ 90% RH
Package weight: 8.0Kg
Product size: 450x450x50mm
