Hand Wave Sensor Button/Microwave Touchless Exit Switch For Access Control
Features
What is Hand Wave Sensor Button?
Hand Wave Sensor Button It is activated by hands waving. After correctly connected this sensor with your power supply and access control system, when you wave your hand at the sensor, the door will turn on automatically.
1. Adopt infrared modulation-demodulation, interference signal will not be caused.
2. With the non-contact induction design, door can be opening an easy and clean way.
3. Transmit distance is adjustable from 1 to 15cm, can be set according to actual occasion.
4. Low-power design with longer service life.
5. Adopt high-sensitivity infrared tubes, quick response for door opening.
6. Installation with hidden screw hole, the appearance with the sense of science.
7. With dry contact signal output, easy to link with various gated equipment.
8. Instruction with light indicator.
9. Power supply: 12-36V DC/AC.
Specification
Protection Level: IP54
Max. Current: 55mA
Max. Voltage: 36V
Product name: Hand Wave Sensor Button
Supply power: AC/DC 12V~36V
Static parameter: DC12V 22mA
Action current: DC12V 55mA
Transmit distance: 1~15CM adjustable
Operation Frequency: 38KHZ
Working environment humidity: -20℃~45℃
Dimension: 113x63x20mm
Fixed way: Fixed with hidden screw
Total Weight: 108g
